FLEXIBLE 700/900 自动高速糊折盒机

One-side gluing

四角盒

4- Corner

锁底盒

Bottom gluing

带盖四角盒

4- Corner with Lid

双边盒

Double-wall gluing

六角盒

6- Corner

侧规部 / Side Register Unit

● 确保纸板在进入折叠工序前，保持精准的平直状态

● Make sure that the paperboard is accurate and straight before entering the folding process

预折叠部 / Pre-Folding Unit

- 适用于需进入自动包装线产品，对于***线（即胶舌）作180°、第三线作135°折返，以方便产品填充实物时的展开。

- 并能为需多次折叠的彩盒，提供辅助折叠功能

- It is suitable for the products that need to enter the automatic packaging line, fold No.1 creasing line 180 degrees and No.3 creasing line 135 degrees, so as to facilitate the opening of the product when filling the material.

- It can also provide auxiliary folding function for boxes that need to be folded many times.

锁底部 / Crash Lock Bottom Unit

- 大/中/小号整套锁底部件、以确保不同大小锁底盒型的准确顺畅制作；

- 上压力传输器为可伸缩设计，可根据不同勾底盒型做灵活调整；

- 开放式机构设计，易于操作；拆装方便；

- Large / medium / small complete set of lock bottom parts to ensure the accurate and smooth production of different sizes of lock bottom box;

- The upper pressure transmitter is of retractable design, which can be flexibly adjusted according to different lock bottom boxes;

- Open mechanism design, easy to operate, convenient to disassemble and install

涂胶单元 / Gluing Unit

● 左右下涂胶单元，均可对胶量做单独精确微调；

● 上涂胶装置，为高速电子喷胶系统；

●  拆装方便，易于清洗和保养；

● Both the left and right bottom gluing units can be used to micro-adjust the glue volume individually;

● The upper gluing device is the high-speed electronic glue gun spraying system;

● Disassembly and installation is convenient, easy to clean and maintain;

本折部 / Final Folding Unit

- 加长行程设计，使纸板在此能充分舒展，顺势做第二线、第四线的折服成型；

- 左右折带180度独立速度可调；

- Extended long journey design, so that the paperboard can fully stretch here, and the second line & the fourth line can be naturally shape into form;

- Left and right folding belt 180 degrees independent speed adjustable;

压着部 / Trombone Unit

- 上下传输器为单独驱动，适用于各种长短盒型；

- 连续、自动积盒方式，确保不同尺寸的纸盒在该部位自然、顺畅的累积；

- 码头齐纸装置；

- 配有自动踢板计数两用装置；

- The upper and lower transporters are driven separately, which are suitable for all kinds of long and short boxes;

- Continuous and automatic carton accumulation ensures the natural and smooth accumulation of cartons of different sizes in this part;

- Alignment device.

- Equipped with automatic kicking & counting device;

输送压力部 / Conveying Unit

● 气动压力调节设计，可精确调整施加压力；

● 采用两条独立进口皮带，柔软适中，配合海绵带，确保产品在胶水固化过程中不会损伤纸品表面。

● 输送部速度根据主机转动速度配合光电器电动自动调节，也可选用手动运转方式及速度；

● The pneumatic pressure adjustment design can adjust the applied pressure accurately;

● Using two independent imported belts, soft and moderate, with sponge belt, to ensure that the product will not damage the surface in the process of glue curing.

● The speed of the conveyor is adjusted automatically according to the rotation speed of the main engine, and the manual operation mode and speed can also be selected;

4/6角系统 / Back Folding Device

- 独立的主控屏操作设置简单，易于掌握；

- 由2组高精度伺服马达驱动电子反勾系统，配合运动控制器，确保2根伺服轴在高速运转中的精确运动；

- The independent main control panel is easy to operate and master;

- Two groups of high-precision servo motors drive the electronic back-folding system and cooperate with the motion controller to ensure the accurate movement of the two servo shafts in high-speed operation;

• 四/六角贴装置

• 爬坡锁底

• 热熔胶喷胶系统

• 等离子处理器

• 90/180度转角

• 订单储存

• 盲文

• 立体盒装置


• 防刮花上纸飞达

• 薄纸上料飞达

• 自动收盒装置

• 质量检测系统

• 胶水检测系统

• 联线喷码/条码检测

• 自动剔除装置


• 4/6 corner devices

• Wave Lock Bottom Device

• Hot glue system

• Plasma treatment system

• 90/180 Turning

• Memory storage

• Braille

• Stereo Box


• Scratch-resistant Feeder

• Thin Paper Feeding Feida

• Automatic box collecting device

• Quality Inspection

• Glue detection system

• Coding Online/Bar Code Detection

• Automatic rejector device
